Traditionally, GPU collective network operations were issued from the framework on a separate CUDA stream than the local computation kernel launches. This allowed overlapping comms and hiding most or all of the network latency. NCCL exposes collectives as fully implemented kernels, and there have been various derivitives such as AMD’s RCCL or Berkeley’s new UCCL project, which is aiming to be a drop-in replacement better suited for large-scale GPU workloads¹. Earlier versions of this sent the networking via the host, and later developed towards GPU-to-GPU peer to peer over connections like NVlink, and direct communication between GPU and the NIC for scale out. But the actual coordination was driven by launches from the CPU.

The increasing capacity of GPUs, particularly in the Hopper/MI300x era, the use of micro-batching, and the rise of Mixture-of-Expert models put a lot more pressure on this arrangement: now rather than a large chunk of comms at the end of each distributed-data-parallel pass you are doing thousands of small exchanges per step. Each step could require each CPU rank to launch thousands of tiny All-to-All: millions of collective calls across the cluster, while still running the rest of the training loop. Each one forces a host interrupt, collective calls and GPU triggers for the data transfer.

A paper from last year, The Landscape of GPU Driven Communication, gives a broad overview of this shift:

In the last decade, several advancements, broadly referred to as GPU-centric communication, have sought to challenge the CPU’s hegemony on multi-GPU execution. At a high level, these advancements reduce the CPU’s involvement in the critical path of execution, give the GPU more autonomy in initiating and synchronizing communication and attempt to address the semantic mismatch between multi-GPU communication and computation.

Getting the right kind of abstractions in here to make this more accessible and flexible is an active area of development. The main reference is the shmem abstraction. This allows writing and reading bytes from remote memory (originally for supercomputers) and adding barriers around usage. Nvidia’s nvshmem (and AMDs ROCshmem) library directly implemented this for GPU.

The next big step up in functionality was GPU Direct Async, a transport that allows access to NIC doorbells directly from the GPU, extending NVSHMEM to RoCE/InfiniBand (Remote Direct Memory Access – RDMA). In addition to this, NVLS (NVLink Sharp) was added to NVLink switches which allowed much more bandwidth efficient switch-managed multicast for broadcast and reduce cases, the fundamental operations used in all-gather and all-reduce collectives. This allows GPU-initiation of collectives which gives us the ingredients to get the CPU out of the networking path completely, and to fuse networking alongside compute operations.

This was one of the things DeepSeek did really well, covered in their DeepEP work: fusing MoE GEMM with GPU-initiated RDMA cut single-node latency by 2–3x. The tradeoff is kernels handle a lot of complexity: choosing between NVLink and GPUDirect for nodes, polling, flow management and so on is tuned to their specific needs and hardware.

ByteDance has also spent a lot of time looking at this problem. Their Flux paper looks at more general approach for doing tile-based fusion of the comms and compute:

Flux overdecomposes computation and communication into tiles. Here, since the computation operation is GEMM, and most high-performance GEMM kernels on GPUs are written with tiling, such as thread block tiling or warp tiling, our decomposition can naturally map into existing tiling in the kernels. Flux fuses dependent communication and/or wait logic into a GEMM kernel, and launches only one fused kernel, compared to the prior methods launching multiple split GEMM kernels.

PyTorch has an experimental feature and RFC for SymmetricMemory:

Then, innovative block-wise compute/computation overlapping techniques started to use copy-engine to drive the P2P traffic in order to minimize contention. Now, we are seeing techniques where NVLink communication is directly issued from “compute” kernels.

[…]

 Just as Triton allows average users to modify matmuls for their needs (fusion, quantization, etc.), we hope that SymmetricMemory will enable average users to modify NVLink communication algorithms for their requirements, whether it’s implementing alternate collective algorithms (one-shot allreduce), using different quantization approaches (stochastic rounding), or fusing collectives with other kernels (all-gather interleaved with matmuls).

This project is still fairly manual, though it abstracts much of the plumbing required and makes it accessible at a high level.

In a similar vein, ByteDance recently released their implementation of Triton-Distributed: ByteDance-Seed/Triton-distributed: Distributed Compiler Based on Triton for Parallel Systems. This adds a small Triton DSL wrapping the shmem operations, supporting both Nvidia and AMD hardware. It exposes some of the comms knobs to autotuning, allowing tuning across compute and collectives, focusing on the tile-based approach they documented in their TileLink paper.

This is unlikely to make its way into upstream Triton, in part because the general approach of Triton is to hide much of the hardware information in the compiler passes, while this approach makes the topology fairly explicit.

The PyTorch team has been working on traceable collectives for the PyTorch compiler. The idea of a compiler being able to look at the overall task graph and decide where to fuse comms and which transport options to use is appealing, as it allows kernels to be more transparent to the specifics of the cluster.

The move to GPU-initiated, fine-grain comms that fuse into compute kernels is real and continuing; the tooling is still early, but the gap will continue to close.

1. This currently host-side controlled, but they have plans for GPU-driven comms as well ↩︎

File this under the “gross oversimplifications” category. The basic approach to keeping GPUs busy is dividing the work into tiles, smaller sub-problems that make up the larger result. For a GEMM you might break the matrix into 128×128 or 128×64 tiles and let each CUDA thread block (CTA) own one tile. The GPU has many streaming multiprocessors (an A100 has 108) and every SM picks up one CTA at a time. If you want to know how many SMs your own card has you can call:

props = torch.cuda.get_device_properties(0)
print(f"SMs: {props.multi_processor_count}")

Tiles are launched in waves. A full wave is the moment when every SM is busy with exactly one CTA. If the total number of tiles isn’t a multiple of the SM count, the final wave is only partly full and some SMs sit idle; Nvidia calls that wave quantization. There is a similar problem at the edge of the matrix: if the dimensions aren’t multiples of the tile size the right-most or bottom-most tiles are partly empty, wasting threads (tile quantization). Sometimes a smaller tile size (for example 64 × 64) gives higher overall throughput because it leaves less unused space at the edges.

The usual cure for poor wave utilization is a persistent kernel. Instead of launching one CTA per tile, you launch (roughly) one CTA per SM and have each CTA pull tiles from a global queue until the queue is empty. Because each CTA is pulls whenever ready, the SMs rarely go idle and the tail effect is reduced.

Inside an SM the main performance lever for GEMMs arethe Tensor Core, which execute matrix-multiply add (MMA) instructions efficiently. On Ampere you use WMMA instructions: one Warp (32 threads) computes a 16 × 16 fragment at a time. Hopper introduces WGMMA instructions where four warps acting in ia warp-group (128 threads) execute a larger matrix multiply (up to 64 × 64 for FP16/FP8). To issue WGMMA you must place the right-hand operand B in shared memory; A can sit in either registers or shared memory. The operation is asynchronous, so while a warp-group is processing one tile the same CTA can be pre-loading the next tile.

Blackwell pushes the idea further. A pair of CTAs on neighbouring SMs can cooperate in a pair unified MMA, letting two SMs’ tensor cores process an even larger tile.

To make that possible Hopper introduced thread-block clusters and Blackwell extends them. When you launch a kernel you can group CTAs into clusters such that the scheduler guarantees to place them on SMs inside the same GPC (GPU Processing Core), so they share a fast interconnect and can access shared memory across SMs. If the grid doesn’t divide cleanly into whole clusters you also lower efficiency on the tail (is this cluster quantization? stick with the trend Nvidia!) so Blackwell has a Cluster Launch Control that can shrink the last cluster to better fit the work.

Loading Data

All of this only works if data is present in shared memory. The first optimization is making sure (global) memory access is coalesced. A 32-thread warp can request 32-byte chunks , but the memory bandwidth for a single fetch from DRAM is wider. e.g. If four consecutive threads request address 1, 4, 8 and 12, the memory controller can coalesce these into a single 128-byte read. If the addresses are strided (e.g. hopping across rows) then only 32 bytes out of the 128 byte fetch capacity is loaded at a time, so the load takes longer. Getting this right is about ensuring the memory layout is set up for the kernel, and doing any transforms needed in shared memory before executing.

In older GPUs the warp had to wait on the copy operation. Ampere enabled cp.async plus non-blocking wait/arrive barriers so a warp can initiate a copy from global to shared memory and immediately continue with arithmetic. Hopper adds the Tensor Memory Accelerator: with TMA, a single thread in the CTA can describe a multidimensional block to copy and the TMA hardware streams it to shared memory while the threads do something else. Blackwell goes one step further and can multicast a single TMA load into every SM of a cluster, which is helpful when multiple CTAs are about to reuse the same B tile.

In practice you hide latency by organizing the main loop using so that it double buffers: while the tensor cores work on tile k the TMA or cp.async engine is fetching tile k + 1 into the other half of shared memory; then you swap buffers and repeat. As long as copy time and compute time overlap well, the tensor cores and the copy engines stay saturated.

Choosing the right tile size

Choosing the right tile size (often expressed in Triton as BLOCK_M × BLOCK_N) is a balance between each of these: enough threads to issue a warp-group MMA, small enough tiles that the matrix edges aren’t mostly padding, enough shared-memory space to double-buffer, and a grid size that fills whole waves or is run via a persistent kernel. Autotuning in Triton or CUTLASS can empirically test different options on the hardware, but it helps to have the right mental model about what sets of sizes they should consider. One good clue that you’re missing an option is when you see a sudden drop in achieved TFLOP/s for particular shape.

AMD

AMD’s MI300X hardware takes a somewhat different route. The GPU is divided into chiplets, where each chiplet has its own compute units and multiple schedulers that schedule wavefronts (AMD for warps, 64 threads rather than 32) independently, so the hardware load-balances multiple kernels by itself. Matrix instructions run at the wavefront level; there is no cross-CU equivalent to WGMMA. Latency hiding relies on launching a large grid of workgroups and letting the hardware interleave them, rather than on explicitly scheduling async copies. On AMD the guidance is to mostly focus on high occupancy and coalesced memory access, whereas on NVIDIA there is value in crafting (by hand or compiler) the copy–compute pipeline.

When data is in the global memory on a GPU it’s usually in row-major or column-major order. Loading from global memory is quite slow though, so for performance we want to move the data to shared memory for the threads in a warp to work on.

To make that load from global memory performance we want memory reads to be coalesced, meaning we are reading contiguous chunk of memory at a time. Shared memory on the other hand is divided into banks, typically 32 banks which are 4 bytes wide. If multiple threads in the same warp try to write to different addresses in the same bank then the requests are processed sequentially, slowing things down while the threads wait on each other. Nsight and other profiling tools will helpfully point this out to you!

For example, let’s say we’re loading a row major and column major tensor, and will be doing a multiplication between them (this is naive, to demonstrate the issue):

__shared__ float Asub[TILE_DIM][TILE_DIM];
__shared__ float Bsub[TILE_DIM][TILE_DIM];  // (No padding in this naive version)
int lane = threadIdx.x;  // 0...31 (warp lane index)
 int tileRow = blockIdx.y * TILE_DIM;
 int tileCol = blockIdx.x * TILE_DIM;
int globalRow = tileRow + lane;
int globalCol = tileCol + lane;
Asub[lane][0] = A[globalRow * N + tileCol + 0];
Bsub[lane][0] = B[(tileRow + lane) + (tileCol + 0) * N];

Now when we fill Bsub we will be writing everything to the same shared memory bank, significantly slowing things down. One easy fix is just to add padding:

__shared__ float Asub[TILE_DIM][TILE_DIM];           // A tile (row-major, no conflict in our case)
__shared__ float Bsub[TILE_DIM][TILE_DIM + PAD];     // B tile (extra column to prevent conflicts)


With PAD as 1 (and TILE_DIM as 32) we have 32×33, or 132 bytes, offsetting the writes and ensuring that each thread gets its own bank.

The downside is that this wastes shared memory, a scarce resource, so an alternative approach is swizzling: changing the layout such that consecutive thread accesses aren’t causing bank conflicts. That’s what Bert implemented to get performance in his recent GEMM walkthrough, but it’s easy to get it wrong.

To make life easier than writing it in raw CUDA, Cutlass has a system called CuTE. Cute is a set of templates to express layout of data:

auto tileLayout    = make_layout(make_shape(Int<32>{}, Int<32>{}), GenRowMajor{});
auto swizzledLayout = composition(Swizzle<5, 0, 5>{}, tileLayout);

Here you specify how the data is laid out in global memory with the shape and stride, then make_layout and the copy operation take care of translating from the row-major layout in global memory to the swizzled layout in shared memory.

From a Triton perspective, Lei Zhang has a great post on memory access, and how it works in Triton, specifically the LinearLayout class that allows the language to similarly handle swizzling and layouts for you:

Indeed the whole point of LLs is that they allow us to specify transposed and swizzled layouts as a “general case”. Instead of a layout class for registers in a thread, and another layout for registers in a thread but in MMAv2 order, and so on, all of these can be represented by different LLs. This gets rid of special cases and lets us write more general code.

There’s a great colfax report on building GEMMS that covers shared memory bank conflicts, and Lei Mao has a post with a nice illustration. Axel Feldman also has a post about benchmarking different approaches and identifying bank conflicts, and some more efficient loading techniques.

In general, branching in GPU code is considered bad. When you write a kernel, it’s very easy to write the same kind of logic as you would on a CPU. However, GPU kernels execute on blocks of threads scheduled on streaming multiprocessors (SMs), and they are optimized for vectorized (or parallel) computation. This optimization relies on the idea that large groups of threads can execute the same instructions on different data in a lockstep fashion. Practically, these are scheduled as “warps” of 32 threads at a time (on Nvidia, the equivalent in AMD is 64 threads).

To work an example , take this naive approach to processing an array that contains both positive and negative values:

__global__ void naive_kernel(const float* input, float* output, int N) {
    int idx = threadIdx.x + blockIdx.x * blockDim.x;
    if (idx < N) {
        if (input[idx] > 0) {
            // Some operation for positive values
            output[idx] = input[idx] * 2.0f;
        } else {
            // Some operation for negative or zero values
            output[idx] = input[idx] + 1.0f;
        }
    }
}

On a GPU, this branching between positive and negative values can lead to warp divergence – you end up using a small number of the threads in the warp, getting worse utilization. Instead, you can rewrite this logic to effectively remove the branching:

__global__ void improved_kernel(const float* input, float* output, int N) {
    int idx = threadIdx.x + blockIdx.x * blockDim.x;
    if (idx < N) {
        // Compute the same math in a unified way
        float val = input[idx];
        // Evaluate the transforms without branching
        float val_pos = val * 2.0f;
        float val_neg = val + 1.0f;
        // Use a conditional assignment
        output[idx] = (val > 0) ? val_pos : val_neg;
    }
}

This rewritten version still makes a choice, but it does so in a way that can be handled more concurrently. The basic idea in GPU programming is to use thread and block IDs to develop kernels that operate cooperatively (for example, splitting data among threads).

This additional idea is branching on the warp itself — which is referred to as warp specialization. It’s very common to have kernels that deal with irregular data access, leading to branching, but by grouping specialized tasks into warps, you can still maintain high utilization of threads.

For example, by branching on the thread ID and using barriers, you can specialize roles in warps, and have one set of threads dedicated to data loading and another to processing the data:

__shared__ int data[128];

__global__ void warp_specialization_kernel(int* global_mem) {
    int idx = threadIdx.x + blockIdx.x * blockDim.x;

    if (threadIdx.x < 32) {
        // Producer warp
        int value = global_mem[idx]; // ... load data from global memory ...
        data[threadIdx.x] = value;
        __namedBarrierArrival("data_ready", 1);
    } else {
        // Consumer warp
        __namedBarrierWait("data_ready", 1);
        int value = data[threadIdx.x - 32];
        // ... process data ...
        global_mem[idx] = value + 42;
    }
}

Here, the first warp (threads 0–31) acts as the producer, loading data into shared memory. The remaining threads (in warps 1, 2, etc.) act as consumers, waiting for the producer to finish before processing the data. The namedbarrierX function calls ensures the producer and consumer warps are synchronized. This sample kernel is simplified to illustrate the concept, but the pattern is useful for specialized tasks.

Triton, with the new changes that landed recently, allows you to specify warp groups in the autotuning parameters:

@triton.autotune(
    configs=[
        triton.Config(
            {
                "BLOCK_SIZE_M": 128,
                "BLOCK_SIZE_N": 256,
                "BLOCK_SIZE_K": 64,
                "GROUP_SIZE_M": 8,
            },
            num_stages=2,
            num_warps=4,
            num_consumer_groups=2,
            num_buffers_warp_spec=3,
        ),
    ],
    key=["M", "N", "K"],
)

num_consumer_groups greater than zero enables warp specialization, and sets how many consumers will be available. num_buffers_warp_spec specifies the how many shared memory buffers are use for transfer between the warp groups. The Triton compiler can then optimize kernels based on available warps, grouping threads intelligently and applying warp-level optimizations, which you can read about in the PyTorch blog post on warp specialization.

One of the reasons for the visibility of this technique now is in the Hopper architecture there are 8 independent schedulers per SM (up from 4 on Ampere) which enables more concurrent execution of warp groups, and the added support for warp-group level instructions, which make synchronization between warp groups pretty cheap.
